The WMT750 Crawler Skid Steer Loader is engineered for ultimate efficiency and versatility. Equipped with a robust engine delivering exceptional power while maintaining fuel efficiency, this loader ensures superior performance across a variety of terrains.
Core Features
Powerful and fuel-efficient engine for maximum productivity.
Compact yet sturdy design suitable for tight spaces and rugged terrains.
Advanced hydraulic system offering precise control and smooth operation.
Easy-to-use control panel ensuring operator comfort and minimal learning curve.
High stability and safety features to protect operators and equipment.
Supported Attachments
The WMT750 supports a wide range of attachments including:
General-purpose buckets
Grapple buckets
Forks
Augers
Snow blowers and sweepers
Hydraulic breakers
These attachments expand the loader’s capabilities, making it perfect for diverse construction, landscaping, agricultural, municipal, and small-scale engineering tasks.
| WMT750 Compact Track Loader Specifications | |
|---|---|
| Engine Brand | Yanmar 380 |
| Rated Power | 17.8 kW (23.9 HP) |
| Cylinders | 3 |
| Emission Standard | EPA |
| Rated Load | 400 kg (882 lbs) |
| Max Load | 450 kg (992 lbs) |
| Digging Force | 4.5 kN (1,012 lbf) |
| Travel Speed | 0-6 km/h (0-3.7 mph) |
| Work Cycle Time | 9 sec |
| System Pressure | 25 bar (363 psi) |
| Fuel Capacity | 30 L (7.9 gal) |
| Operating Weight | 1,200 kg (2,646 lbs) |
| Track Width | 180 mm (7.1 in) |
| Max Operating Height | 2,900 mm (114.2 in) |
| Height to Bucket Pin | 2,160 mm (85 in) |
| Overall Height | 1,540 mm (60.6 in) |
| Length Without Bucket | 2,100 mm (82.7 in) |
| Length With Bucket | 2,700 mm (106.3 in) |
| Bucket Capacity | 0.15 m³ (5.3 cu ft) |
| Discharge Height | 1,600 mm (63 in) |
| Discharge Reach | 450 mm (17.7 in) |
| Bucket Tilt Angle | 114° |
| Wheelbase | 1,180 mm (46.5 in) |
| Ground Clearance | 180 mm (7.1 in) |
| Machine Width | 980 mm (38.6 in) |
| Bucket Width | 1,100 mm (43.3 in) |
